A harmonic or reactive-power study can show that an active harmonic filter (AHF) or static var generator (SVG) has enough compensation capacity for a bus. That does not prove the panel can be connected safely to that bus. Before connection, the project team must also compare available fault current, equipment and assembly short-circuit ratings, protection settings, grounding arrangement, isolation method and bypass behavior.
Quick answer: Verify the available short-circuit current at the intended connection point, then compare it with the documented rating of the complete AHF or SVG assembly—not only an individual converter module. Review upstream and branch protective devices, cables, busbars, grounding, isolation and bypass arrangements as one protection chain. The equipment’s rated compensation current is not a substitute for its short-circuit rating or a site fault-level calculation.
Electrical drawings often place several current values near each other. They answer different questions.
A 200 A SVG may be suitable for a reactive-power duty while the connected bus has a much higher available fault current. The safety question is whether the complete panel, its protective device and the upstream system are correctly rated and coordinated for that condition.
Fault level is location-dependent. Moving a panel from a downstream feeder to a main low-voltage bus can change the available short-circuit current materially. Transformer size and impedance, utility contribution, parallel transformers, busway length, generator operation, tie breakers and future upgrades can all change the result.
Mark the intended connection point on the current single-line diagram. Request the latest available fault-current study, transformer data and protection settings. If the project includes utility and generator modes, assess both. Generator contribution and protection behavior can differ from normal utility supply.
| Input to verify | Why it matters | Typical source | Common error |
|---|---|---|---|
| Available short-circuit current at connection point | Defines the fault duty seen by the assembly | Short-circuit study or responsible electrical engineer | Using a value from another bus or an old drawing |
| Transformer rating and impedance | Strongly affects downstream fault current | Transformer nameplate and study | Assuming kVA alone defines fault level |
| Assembly short-circuit rating | Must cover the actual installation duty under stated conditions | Panel documentation and verification record | Checking only the converter module rating |
| Breaker or fuse characteristics | Determines clearing time and coordination | Protection schedule and manufacturer data | Selecting by normal load current only |
| Busbar and cable withstand | Must survive the fault until cleared | Assembly drawing and cable design | Ignoring internal links or bypass conductors |
| Grounding arrangement | Affects fault path and protective response | Single-line diagram and grounding study | Treating grounding as a panel-only detail |
| Bypass and isolation design | Determines safe maintenance and fault segregation | Approved schematic and operating procedure | Adding an undocumented bypass later |
Low-voltage switchgear and controlgear assemblies are evaluated as assemblies, not as a loose collection of individually rated parts. IEC 61439 addresses design verification for low-voltage switchgear assemblies, including short-circuit withstand considerations. The applicable part, verification route and local code requirement must be confirmed by the responsible engineer and the project specification.
For an AHF or SVG panel, the relevant path includes more than the power converter. It can include the incoming breaker or fuse, contactors, busbars, internal links, current transformers, bypass device, cable terminations, earthing conductor, enclosure and control power. The lowest applicable rating or an unverified interface can become the limiting point.
Ask for the assembly rating in the form relevant to the project. If a conditional short-circuit rating relies on a particular upstream protective device, confirm the device type, rating, setting and installation arrangement match the documented condition. Do not assume that replacing a breaker with a larger one preserves the original verification.
A coordinated protection system should identify which device clears which fault, how quickly it acts and what remains energized afterward. The exact design belongs to the qualified project engineer, but the project review should address the following questions.
Protection settings should never be altered merely to stop a nuisance trip. A repeated trip can indicate a true fault, incorrect CT wiring, unsuitable settings, a thermal problem, inrush, coordination error or a system condition outside the original design assumptions.
A site acceptance plan should distinguish external system faults from internal equipment events.
| Event | What to verify | Useful evidence |
|---|---|---|
| External bus or feeder fault | Branch protection clears or withstands the event as designed | Study reference, protective-device settings and event record |
| Converter overcurrent | Equipment enters its approved limit or trip sequence | Alarm code, time stamp and operating procedure |
| DC-bus abnormality | Controlled protection response and safe reset condition | Event log and reset authorization |
| Overtemperature or fan failure | Warning, derating or trip follows the approved logic | Temperature trend, alarm test and maintenance procedure |
| CT loss or phase mismatch | Controller alarms or inhibits unsafe compensation | Functional test and wiring verification |
| Communication loss | Defined fallback behavior without uncontrolled output | Network test and configuration record |
| Bypass operation | Isolation and interlocks work without exposing personnel or equipment | Switching procedure and witnessed test |
A functional test does not need to create a damaging high-current fault. It should use approved test methods, simulations, secondary injection or documented manufacturer procedures appropriate to the equipment and site safety rules.
A fault level can change after a transformer replacement, bus-tie modification, new utility service, generator addition, capacitor-bank change, source parallel operation or major expansion. Even when the AHF or SVG panel is unchanged, the installation duty may no longer match the original study.
For retrofit projects, do not rely only on drawings from the previous installation. Confirm what is actually installed, including breaker frames and trip units, cable routes, busbar sections, grounding links and any field-added bypass. Compare the as-built condition with the equipment documentation before energization.
Consider a 400 V AHF panel proposed for connection to a plant main bus. The harmonic study recommends 150 A of compensation. The electrical review must still obtain the bus fault level, transformer impedance, upstream breaker data and the panel’s documented assembly rating. It must check whether the proposed feeder breaker and cable are the same arrangement assumed by the panel verification, and whether a maintenance bypass changes fault paths.
If the plant later adds a second transformer with a closed bus tie, the available fault current may increase. The 150 A compensation requirement may remain unchanged, yet the protection and assembly review may need to be repeated. Harmonic sizing and fault-duty verification are separate engineering tasks.
For related installation context, review our AHF installation and commissioning guide and project-data checklist.
No. A larger breaker can reduce protection for conductors or panel components and may invalidate a conditional short-circuit arrangement. The device must be coordinated with the complete assembly and the site study.
No. Rated compensation current describes normal operation. Short-circuit rating and available fault current address fault conditions and must be reviewed separately.
No. Bypass design affects isolation, protection, interlocks and fault paths. It should be included in the approved schematic and reviewed with the equipment manufacturer and responsible engineer.
A safe connection requires both the correct compensation capacity and a verified protection path. Send the current single-line diagram, transformer impedance, available fault current, protection schedule, panel documentation and source-mode information to Elumotive for an initial connection review.
